A bigger Milwaukee-Eight® 117 Classic engine brings more power, and improved SHOWA® dual-bending valve front suspension is comfortable on the highway and composed during cornering.
Vehicle shown may vary visually by market and may differ from vehicles manufactured and delivered
Loading 360 images
DRAG BIKE FOR 360 VIEW
Milwaukee-Eight® 117 Classic
156 Nm
293 kg
680 mm
Clear, bright LED turn signals let everyone on the road know where you’re going, and a 146 mm LED headlight provides a wide beam of bright white light.
Five available paint options now feature the iconic “stretched diamond” black-and-chrome tank medallion, based on Willie G.’s original 1966 design
Now available with blacked-out, cast Annihilator wheels or new tubeless laced wheels. A 483 mm front wheel with 406 mm rear delivers a classic bobber silhouette.
With mini ape-hanger handlebars, a slim 13.2 l gas tank, and a short, bobbed-style rear fender, the Street Bob has classic bobber style straight from the factory.
Type | Milwaukee-Eight® 117 Classic |
Bore | 103.5 mm |
Stroke | 114.3 mm |
Displacement | 1,923 cc |
Compression Ratio | 10.3:1 |
Fuel System | Electronic Sequential Port Fuel Injection (ESPFI) |
Exhaust | 2-into-1; catalyst in header |
Length | 2,320 mm |
Seat Height, Unladen | 680 mm |
Ground Clearance | 125 mm |
Rake (Steering Head) (Deg) | 30 |
Trail | 157 mm |
Wheelbase | 1,630 mm |
Tires, Front Specification | 100/90B19,57H,BW |
Tires, Rear Specification | 150/80B16,77H,BW |
Tyre, Type | Dunlop® Harley-Davidson Series, bias blackwall front and rear |
Fuel Capacity | 13.2 l |
Oil Capacity (W/Filter) | 4.7 l |
Weight, In Running Order | 293 kg |
Engine Torque Testing Method | EC 134/2014 |
Engine Torque | 156 Nm |
Engine Torque (RPM) | 2750 |
Horsepower | 91 HP / 68 kW @ 5020 rpm |
Lean Angle, Right (DEG.) | 28.5 |
Lean Angle, Left (DEG.) | 28.5 |
Fuel Economy Testing Method | EU 134/2014 |
Fuel Economy | 5.5 l/100 km |
Co2 Emissions Testing Method | EU 134/2014 |
Co2 Emissions | 128 g/km CO2 |
Primary Drive | Chain, 34/46 ratio |
Gear Ratios (Overall) 1st | 9.311 |
Gear Ratios (Overall) 2nd | 6.454 |
Gear Ratios (Overall) 3rd | 4.793 |
Gear Ratios (Overall) 4th | 3.882 |
Gear Ratios (Overall) 5th | 3.307 |
Gear Ratios (Overall) 6th | 2.79 |
Front Fork | Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; gaiter covers |
Rear Shocks | Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment |
Wheels, Optional Style Type | Painted aluminum tubeless laced wheel |
Wheels, Front Type | Black, Annihilator cast aluminum |
Wheels, Rear Type | Black, Annihilator cast aluminum |
Brakes, Caliper Type | 4-piston fixed front and 2-piston floating rear |
Lights (As Per Country Regulation), Indicator Lamps 6 | Headlamp: All LED, low beam, high beam and signature position lamp; Tail/Stop: Bullet-style, LED stop/tail/turn signals; Front Signal Lights: LED Bullet Turn Signals |
Gauges | 102 mm (4-inch) analog speedometer with digital gear, odometer, fuel level, ride modes, heated gear, traction control, ABS, TPMS, cruise control, clock, trip, range and tachometer indication |
Street Bob™
Offer Ends 31/12/2025
H-D - 6.6% APR Representative Across All Models*
All new Harley-Davidson® models now available with rates from 6.6% APR Representative
Embrace the road with a new Harley-Davidson. Freedom awaits.
Twist the throttle on new adventures and ride away for less. Where the road opens up, your Harley® story truly begins. The road ahead is yours for the taking. Ride away today for 6.6% APR Representative on new Harley-Davidson® models*
PCP Representative Example based on MY24 Ultra Limited in Billiard Gray™
On The Road Price | £30,395.00 |
Deposit | £6,000.00 |
Annual Mileage | 4,000 |
Bolt-On Accessories Cost | £0.00 |
Warranty Cost | £0.00 |
Duration of Agreement (months) | 36 |
Total Amount of Credit | £24,395.00 |
Total Charge for Credit | £3,766.60 |
Optional Final Repayment | £14,599 |
Purchase Fee | £10.00 |
Total Amount Payable | £34,161.60 |
APR Representative | 6.6% APR |
Interest Rate (Fixed) | 6.41% |
Excess Mileage Rate | 6p per Mile |
6.6% APR Representative Promotion
KEY TERMS
*Offer available on new retail sales only, excludes Trike, CVO and Icons. Finance offer ends 31st December 2025. Credit is subject to status and only available to UK residents aged 18 and over. 10% minimum deposit required. Guarantee may be required. Hire Purchase or Personal Contract Purchase plans available. Harley-Davidson Finance, OX14 4SD is a credit broker, not a lender. Finance provided by Black Horse Ltd, CF10 5BH. Finance subject to status, 18+ Ts & Cs apply. Models shown for illustration purposes only.
1.The promoter of the Promotion is Harley-Davidson Europe Limited 192B Park Drive, Milton Park, Oxfordshire OX14 4SD (“Harley-Davidson”)
2. The Promotion entitles each customer who during the Promotional Period purchases a new Harley-Davidson unregistered motorcycle, excluding Trike, CVO and Icon variants, through a Harley-Davidson Finance (“HDF”) financing program to receive a financing rate of 6.6% (six point six percent) APR Representative, 10% minimum deposit required while stock lasts.
3.The Promotion is available to customers until 31 December 2025 (the “Promotional Period”) the motorcycle must be registered within the promotional period to qualify and offered subject to credit acceptance though HDF (a trading style of Blackhorse Ltd) in the UK.
4. This offer is subject to Credit acceptance which is subject to status and approval and is only available to UK residents over 18. Credit in the UK is provided by Harley-Davidson Finance, a trading style of Blackhorse Ltd, St William House, Tresillian Terrace, Cardiff CF10 5BH. Blackhorse is authorised and regulated by the Finance Conduct Authority in the UK. Lending criteria and conditions apply (over 18s only).
5. The dealer you purchase the bike from will usually receive a commission for your introduction. This will either be a fixed fee, or a fixed percentage of the amount you borrow. You will not pay it to us. The exact amount of commission will be confirmed before you sign your finance agreement.
6. Promotion available only at authorised Harley-Davidson dealerships in the United Kingdom.
7. Harley-Davidson reserves the right to amend the terms of the Promotion or to withdraw the Promotion at any time if circumstances beyond its control make this unavoidable, or to refuse redemption of the Promotion in the event of non-compliance with these terms and conditions.
8. With the exception of liability which cannot be excluded by law, Harley-Davidson and any other companies in its corporate group is not liable for, and customer releases Harley-Davidson and any other companies in its corporate group from, liabilities relating to any direct or indirect loss or damage which is suffered as a result of the Promotion.
9. The Promotion and the terms and conditions which apply to the Promotion will be governed by and construed in accordance with the law of England and Wales.
